ROOT ZONE WATERING SYSTEM
For young plants and trees to thrive, they must receive adequate irrigation and a steady exchange of oxygen across all levels of the root zone. This encourages roots to grow deep and remain safely below ground, allowing plants to become strong and fully established. Developed to meet this challenge, the Root Zone Watering System features patented StrataRoot™ design, a series of internal baffles that direct water, oxygen, and nutrients to the root zone and provide rigidity to the irrigation cylinder for added durability. The RZWS comes pre-assembled for easy installation, and the enclosed design and grate protect irrigation hardware from vandalism. For efficient irrigation of trees and shrubs delivered throughout the root zone, the RZWS is the optimal solution.
RZWS-10
|
Diameter |
: 5.1 cm |
|
|
Length |
: 25 cm |
RZWS-18
|
Diameter |
: 7.6 cm |
|
|
Cap Diameter |
: 12 cm |
|
|
Length |
: 45 cm |
RZWS-36
|
Diameter |
: 7.6 cm |
|
|
Cap Diameter |
: 12 cm |
|
|
Length |
: 90 cm |
RZB
|
Diameter |
: 5.1 cm |
|
|
Length |
: 23 cm |
Operating Specifications
- Bubbler flow rates: 0.9 l/min or 1.9 l/min
- Recommended pressure range: 1.0 to 4.8 bar; 100 to 480 kPa
Factory Installed Options
- Check valve
- Locking reclaimed purple cap
User Installed Options
- Fabric sleeve that helps prevent soil intrusion in sandy areas for 45 cm and 90 cm models (P/N RZWS-SLEEVE)
- Replacement cap for 45 and 90 cm models (P/N 913300SP)
- Locking reclaimed purple cap for 45 and 90 cm models (P/N 913301SP)
- Reclaimed water purple cap for 25 cm (P/N RZWS10-RCC)
